RNJOP

Physical Contact Connectors – European Standards

DOWNLOAD A DATASHEET

Specifications

  • C41 indoor (C41: Communication Control Command Computer Intelligence)
  • Navy
  • In flight entertainment
  • Robotic machining

Specifications

Description Measurement/Detail
Optical Tech Butt joint
Shell Type Circular
Optical Cleaning Difficult: cotton tip + alcohol + air spray
Sealing Contact us
Mating Cycles >200
Operating Temperature (°C) Min: contact us max: contact us
Single Mode Insertion Loss & Return Loss (dB) Typical: non applicable max: non applicable
Multimode Insertion Loss (dB) Typical: 0.7 max: 1
Cable Types
Channels 2, 4, 5, 6 & 8
Fiber Multimode
Coupling Device Rack & panel
Plug Outer Diameter or Dimensions (mm (inch)) 23 to 30 (.91 – 1.18)
